50ml Spraying Assembly Line Checkweigher Online Check Weighing Conveyor System
The assembly line automatic checkweigher is an automatic device used in the automatic packaging production line to check the weight of the product. It can check whether the product's weight meets the standard weight we set in the continuous work process. Online check weighing conveyor system high -speed, high -precision, stable operation, simple operation, multiple rejection system options, and a complete packaging line with upstream and downstream equipment. Any OEM and customer design orders are welcome! If you are interested in our products, please feel free to contact us.
Assembly line automatic checkweigher pictures
Type SG-150U
Weighing Range 3-500g
Limited of product L: 100 W:150 H: 3-200mm
Accuracy ±0.1g Depends on product
Division Scale 0.1g
Belt Speed 0- 60 m/min
Max Speed 150 pcs/min
Belt Width 150mm
Machine Weight 60kg
Power Supply AC 220V ±10% 50HZ
Power 100W
Main Material SU304 stainless steel
The above parameters are for reference only and can be customized according to the requirements. Generally speaking, customers need to provide the following parameters to determine the specifications of assembly line automatic checkweigher.
[Product Size and range] ___________________mm
[Product weight range] __________________g
[Detection speed] ____________________________________________ p/min
[Detection accuracy] ______________________g
[Facing the screen conveying direction] Left to right to the left
[Belt distance to the ground height] ____________________mm
[Use environment] ______________________________________
The above information can determine the specifications of the online assembly line automatic checkweigher.
1. Ultra -high equipment environment adaptability.
2. A friendly operation interface.
3. Modify the parameters at any time without the need to suspend the sorting machine without weight.
4. Up to 200 products preset, can store hundreds of thousands of data records to meet the complex needs of customers.
5. Rich peripheral resources and easily realize interconnection with other equipment.
6. Quickly dynamicly referred to as the re -algorithm software technology, so that the entire system can also maintain high detection accuracy during high -speed operation.
1. The assembly line automatic checkweigher is applied in the electronics and toy industry: parts of parts missing parts (such as toys missing parts, screw packs, lack of parts detection, TV and set -top boxes such as lack of parts detection);
2. Application of automatic checkweighers in the daily product industry: Cosmetics lack of parts, whether the entire bag of laundry is lacking bags, whether the whole box of toothbrushes is missing;
3. The dynamic checkweigher machine is applied in industries such as hardware: stainless steel tableware and knife lack of components;
4. The application of automatic examination in the pharmaceutical industry: drug lack of bag detection, whether the entire box of drugs lack the instruction manual, whether the net content of the drug is qualified;
5. The online check weighing systems are applied in the food industry: convenient noodles such as instant noodles, whether the entire box of biscuits lack a small number of biscuits.
Shanghai Shigan Industrial Co., Ltd. is a manufacturer specializing in a online checkweigher and automatic metal detector machine. Products are widely suitable for food, medicine, daily necessities, chemicals, toys. Hardware and other industries. Our company's production online checkweigher and automatic metal detectors are sold in dozens of countries and regions around the world in Europe, Asia, Africa, South America, and the Middle East. Working teams provide customers with comprehensive after -sales service in a timely manner. Innovate, pragmatic, and efficient, win trust with responsibility! Shanghai Shigan provides a complete one -stop service for more corporate customers around the world!
Our main products
Checkweigher for Food industry
Checkweigher for the pharmaceutical industry
Checkweigher for Cosmetics industry
Checkweigher for Daily Necessities
Checkweigher for Hardware fitting
Checkweigher with metal detector
Packaging
Film pack inside, Wooden case outside
Shipping
1. Upon receipt of payment, delivery date will be in 20-30 working days
2. By Air, by Sea or by Express (DHL, UPS, TNT, EMS, etc.)
1. Consultation and assessment: Understand customer requirements, production processes and quality control goals, and determine the most suitable online check weighers solutions that are most suitable for its specific needs.
2. Product demonstration: Intigically understand the operation of the equipment and directly evaluate its performance.
3. Installation and debugging: After purchasing, the online check weigher is installed and debuged by trained technicians to ensure that it is seamlessly integrated into the customer's production line.
4. Technical support: Provide continuous technical support to solve any questions, problems, or maintenance needs that occur during the operation of the online check weighers.
5. Maintenance range: 1 year warranty, lifelong maintenance.
We aim to provide customers with correct solutions, support, and peace of mind during the entire life cycle of the equipment, ensure that the online check weigher meets the needs of customers and provide long -term value.
