30kg Heavy Duty Metal Detector For Production Line Inline Metal Detector For Foood Pharma Industry

sku:

The inline metal detector for foood pharma is used to detect metal magazines or metal foreign matters mixed in food, medicine and other enterprise products. It adopts in balance principle, and has more stable and reliable performance. The automatic metal detector for production line adopts phase adjustment technology, which can adjust the product and effectively restrain the product effect.

tag:

Description

30kg Heavy Duty Metal Detector For Production Line Inline Metal Detector For Foood Pharma Industry



The inline metal detector for foood pharma is used to detect metal magazines or metal foreign matters mixed in food, medicine and other enterprise products. It adopts in balance principle, and has more stable and reliable performance. The automatic metal detector for production line adopts phase adjustment technology, which can adjust the product and effectively restrain the product effect.Our product specifications and sizes are rich, various styles, welcome to contact us for quotation information.



Inline metal detector for foood pharma pictures

Metal Detector For Foood Pharma Industry

Metal Detector For Production Line

Heavy Duty Metal Detector








Detection height: 80mm (acceptable)


Detection width: 400mm (acceptable)


Belt speed: about 26m/min (acceptable)


Detection sensitivity: Fe (diameter) ≥ 0.8mm, Sus (diameter) ≥ 1.5mm


Power: 90W


Voltage: AC220V/50~60Hz (110V optional)


Working temperature: - 20 ℃~60 ℃


Boundary dimension: 1330 * 980 * 1030 (mm)


Weight: 280K (g)


Size of detected metal: 0.6mm


Measuring range: all metals


Alarm mode: audible and visual alarm, shutdown or elimination optional


Working power supply: 220 (V)


Parameters are for reference only and can be customized according to requirements




We persist in solving every customer problem, meeting customer needs, improving products and services. Non standard products can be customized according to customer needs.





1. The body is made of all stainless steel 304 wire drawing, and the conveyor belt is a white non-toxic food-grade PU special conveyor belt that meets the US FDA standard.

2. LCD display, Chinese and English menu-style pictures, easy to realize man-machine dialogue operation.

3. It has a memory function. Through the fast self-learning function, it can be used once automatically set and has a memory function. It can store more than 100 product detection parameters, which can be adapted to more product groups.

4. Good waterproof performance, suitable for damp, cold storage and other environments.

5. It can pass water-containing, salt-containing and oil-containing products.

6. The probe is a digital all-metal probe, filled with epoxy resin to ensure the stability and service life of the equipment

7. The motor speed is 26-35 meters per minute (speed-regulating motor is optional), and supports 24 hours of uninterrupted work.

8. Conveying direction: facing the operation panel from left to right, the height of the conveyor from the ground, 700mm

9. Motor power: 120w; power supply, AC220V±10%, 50-60Hz.



1. Detect metal impurities in food, medicine, toys, shoe materials, textiles, daily chemical products, chemicals and other industrial products to ensure that the products are free of metal pollution and provide reliable quality assurance.


2. Detect metal impurities in raw materials of plastics, textiles, wood, mining and other industries, protect key equipment, reduce downtime, maintenance time and costs, and improve work efficiency.








Shanghai Shigan Industrial Co., Ltd. is located in beautiful Shanghai, China. Since 2010, it has been engaged in the production and development of assembly line packaging weighing equipment, and has obtained CE certification and several professional certificates. The company always adheres to the business philosophy of "innovation, quality and efficiency" to provide you with perfect and high-quality products and services. Now our products have been sold all over the world and won the trust and praise of countless customers!

Our main products include: inline checkweigher, automatic metal detector, vertical packaging machine, prefabricated bag packaging machine, multi head weigher, linear scale, and a series of assembly line packaging detection equipment.
















A. Pre-sale:

1. Provide real quotations for customers according to customer requirements, and timely record feedback when customers have special requirements;

2. Sign a standardized product order contract, clarify responsibilities and other related matters;

3. Provide one-year free warranty, lifetime maintenance service, and be responsible for debugging the product before shipment;


B. After sale:

1. If the customer's product fails, we will provide you with a solution as soon as possible;

2. During the warranty period, the product is repaired free of charge. If the warranty period is exceeded, repairs can also be provided. If the parts are replaced, the product parts will be provided at the cost price.
